Energy Quality




             Network Analysers / DKM-409




       DKM-409 Series
       Network Analyser


       The DKM-409 is a precision instrument designed for displaying
       various AC parameters in 3-phase distribution panels.

       Thanks to its isolated RS-485 Modbus RTU communication port,
       the device is free from ground potential difference issues and
       measured parameters are safely transferred to factory and
       building automation systems.
       The graphic screen allows display of waveforms and harmonic
       analysis graphs. Various display screens can be scrolled automatically.
       The user configurable screen where any measured parameter set can be
       displayed, transforms the unit to a custom designed measurement panel.
       The unit fits into a standard 92x92mm panel opening















                            B&W Screen (2.9”)  Color Screen (3.5”)  RS-485 Modbus  Digital Inputs  Digital Outputs  Analog Outputs  USB Port  Isolated Current Input  Ground Current Input  DC Supply  AC Supply  1 mA Measurement  Record Memory  Real Time Clock  Accuracy %  True RMS  Harmonics  Micro-SD Card  Ethernet  USB Host  GPRS Modem








         DKM-409 - S       ■                                      ■                 0,5  ■  31                   Wi-Fi
         DKM-409 - S4      ■       ■                              ■                 0,5  ■  31
         DKM-409           ■       ■   2   2                      ■                 0,5  ■  31
         DKM-409-T-S       ■                      ■   ■           ■   ■   1MB   ■   0,5  ■  49
         DKM-409-T-S4      ■       ■              ■   ■           ■   ■   1MB   ■   0,5  ■  49
         DKM-409-T         ■       ■   4   2      ■   ■           ■   ■   1MB   ■   0,5  ■  49
         DKM-409 - Pro     ■       ■   4   2   2  ■       ■       ■       1MB   ■   0,5  ■  31  ■
         DKM-409 - Pro - At - AC  ■  ■  4  2   3  ■   ■           ■   ■   1MB   ■   0,5  ■  49
         DKM-411 MK3           ■   ■   2   2      ■               ■             ■   0,2  ■  63      ■   ■
